Extension lines with stopcocks
Connect-A-Set 3 (with Bionector)
Popis
Triple layer extension tube (PVC/VYG2/PE) with lipid resistant three-way stopcock and Bionector on the lateral port of the stopcock (5141.01/00/10)… Přečtěte si více
Indikace
IV catheter extension tube with 3-way stopcock and Bionector. Add-on device for I.V. catheter.
Popis
Triple layer extension tube (PVC/VYG2/PE) with lipid resistant three-way stopcock and Bionector on the lateral port of the stopcock (5141.01/00/10) or with two Bionector on each female port of the stopcock (5141.011/001).
Reference a funkce
| Extension tube | Balení | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| Favourites | Kód | Int. Ø mm | Ext. Ø mm | Priming volume ml | Length cm | Longitudinal flow rate ml/min | Transversal flow rate ml/min | Jednotky/balení | Jednotky/karton |
| 5141.00 | 2.5 | 4.0 | 1.70 | 25 | 390 | 80 | 50 | 200 | |
| 5141.001 | 2.5 | 4.0 | 1.70 | 25 | 76 | 76 | 50 | 200 | |
| 5141.01 | 2.5 | 4 | 1.1 | 13.5 | - | - | 50 | 200 | |
| 5141.011 | 2.5 | 4 | 1.1 | 13.5 | 86 | 86 | 50 | 200 | |
| 5141.10 | 2.5 | 4.0 | 5.40 | 100 | 380 | 80 | 25 | 150 | |
Další informace
-
Obsahuje latex Ne
-
Obsahuje živočišný produkt Ne
-
Bez pyrogenu Ano
Dokumentace
-
Bionector Product Range
-
Návod k použití
